Eco-Tech Pump’s offers a broad range of pumps designed to handle challenging solids applications, with discharge sizes ranging from 1.25″ to 30″. These pumps are commonly used in the Municipal, Agricultural, and Industrial markets and can be mounted in several configurations, including close-coupled, SAE engine, horizontal, and vertical. With enclosed, semi-open, and delta impellers, and a variety of construction materials, Eco-Tech solids handling pumps can achieve flow rates up to 40,000 GPM.

All Eco-Tech solids handling pumps come equipped with the heavy-duty bearing frame that is easily recognizable by its angular, muscular appearance, and is a hallmark of high-quality Eco-Tech pumps.

SHP14-TG28 Solids Handling Pumps

SHP14-TG28 series pumps are made to tackle challenging solids handling applications, with discharge sizes ranging from 1.25" to 30". These pumps are adaptable to various mounting options, including close-coupled, SAE engine-mount, horizontal frame-mount, and vertical coupled. They have enclosed impellers capable of handling up to 10" solids and 40,000 GPM flow, but also offer the option of a delta impeller for dealing with stringy materials and rags. The SHP14-TG28 series has been trusted in wastewater handling for over 30 years, thanks to its sturdy and reliable design.

Key Features Specifications Selection Chart

Here are the key features of Solids Handling Pumps:

●  Designed to pump liquids containing suspended solids and debris.

●  Large free passage impeller to prevent clogging.

●  Capable of handling soft and hard solids without damage.

●  High wear resistance for abrasive applications.

●  Heavy-duty construction for demanding industrial environments.

●  Efficient hydraulic design for reliable performance.

●  Self-cleaning impeller options available on many models.

●  Suitable for high-volume and high-flow applications.

●  Available in submersible and dry-installed configurations.

●  Excellent resistance to corrosion and erosion.

●  Low maintenance requirements due to clog-resistant design.

●  Can handle sludge, slurry, sewage, wastewater, and fibrous materials.

●  High pumping efficiency with reduced downtime.

●  Robust mechanical seals for extended service life.

●  Available in various materials such as cast iron, stainless steel, and duplex stainless steel.

●  Designed for continuous-duty operation.

●  Energy-efficient motor options available.

●  Easy inspection and servicing with simplified maintenance access.

●  Compatible with automatic control and monitoring systems.

●  Reliable performance under harsh operating conditions.

These features make solids handling pumps ideal for industries such as:

●  Oil & Gas

●  Wastewater Treatment

●  Mining

●  Chemical Processing

●  Pulp & Paper

●  Food Processing

●  Power Generation

●  Municipal Sewage Systems

●  Construction and Dewatering

●  Agriculture and Irrigation

OPERATING LEVELS

MIN FLOW	3000 GPM	681 m3/h
MAX FLOW	13800 GPM	3132.6 m3/h
DISCHARGE SIZE	14”	356 mm
SUCTION SIZE	14”	406.4 mm
SOLIDS HANDLING	4.25”	10.6 cm
MAX SPEED	1200 RPM	1200 RPM
SHUT-OFF HEAD	425’	129.5 m
BEP HEAD	300’	91.5 m
BEP FLOW	11600 GPM	2633 m3/h
BEP PERCENT	85%	85%
